Acoustic Movable Partition Wall with 800N Sealing Power and 40N/m Magnetic Attraction for Banquet Halls

Acoustic Movable Partition Wall with 800N Sealing Power and 40N/m Magnetic Attraction for Banquet Halls

ব্র্যান্ড নাম: AE
মডেল নম্বর: AE85
MOQ.: 10 বর্গ মিটার
মূল্য: USD 80-100 per square meter
অর্থ প্রদানের শর্তাবলী: টি/টি, এল/সি, ওয়েস্টার্ন ইউনিয়ন
সরবরাহের ক্ষমতা: প্রতি মাসে 1000 বর্গ মিটার
বিস্তারিত তথ্য
উৎপত্তি স্থল:
গুয়াংডং, চীন
সাক্ষ্যদান:
ISO9001 SGS CANS
মডেল:
চলমান পার্টিশন ওয়াল
বেস বোর্ড:
এমডিএফ বোর্ড
সম্মতি:
মিটিং রুম, কনফারেন্স রুম
পুরুত্ব:
89 সেমি
STC রেটিং:
42-56dB
মাত্রা:
কাস্টমাইজেশন (উচ্চতা: 6 মি পর্যন্ত, প্যানেল প্রতি প্রস্থ: 1.2 মিটার পর্যন্ত)
নাম:
চলমান পার্টিশন ওয়াল
প্যাকেজিং বিবরণ:
প্লাইউড কেস বা ইস্পাত প্যালেট সহ ফোম স্তর এবং হার্ড কার্ডবোর্ড
বিশেষভাবে তুলে ধরা:

800N Sealing Power Movable Partition Wall

,

40N/m Magnetic Attraction Movable Partition Wall

,

MDF Board Movable Partition Wall

পণ্যের বর্ণনা
Banquet Hall Acoustic Movable Partition Wall
AE Operable Partitions are a system of multiple panels suspended from tracks, designed for banquet halls and large spaces. These manually operated partitions require no special equipment - just the included operating handle to lock and engage the mechanical seals at top and bottom, ensuring acoustic sealing when closed.
Key Advantages
  • Extensive experience serving major clients worldwide
  • Flexible order delivery time management
  • Dedicated design team for continuous product innovation
  • SGS and ILAC-MRA certified product performance
  • German partition technology integration for professional space solutions
  • Extended service life for all professional products
Roller System Features
  • Premium Dupont POM rollers for smooth operation
  • Heavy-duty 304 stainless steel rollers with safety devices and CNC machining
  • Patented wheel design enhances overall partition system performance
Panel Specifications
  • 89mm thickness for superior stability and sound insulation
  • Multiple acoustical and decorative finish options available
  • 6061-T6 aluminum profile with Q235 steel frame construction
  • 800N jack lifting mechanism with 40N/m magnetic seal for secure closure
Technical Specifications
Series Element Thickness (mm) Element Width (mm) Clear Height (mm) Construction Vertical Profile Design
AE65 68 600-1,250 2,000-4,500 Aluminium-steel Magnetic strip with sealing lips
AE85 89 600-1,250 2,000-5,500 Aluminium-steel Magnetic strip with sealing lips
AE100 105 600-1,250 2,000-18,000 Aluminium-steel Magnetic strip with sealing lips
Sound Reduction: Weighted sound reduction value (Rw) of 52-56 dB (GB/T19889.3-2005)
Sealing Technology: Convex-concave profile with 40 N/m magnetic attraction force
